PVS-14 Night Vision Monocular (Black)


From N-Vision Optics | Model #: NVPVS14AG3B



See more in


PVS-14 Night Vision Monocular (Black)

Product Description

The black PVS-14 Night Vision Monocular from N-Vision is a Gen III image intensification device designed for tactical professionals and first responders. At the core of the PVS-14 is a third generation image intensifier tube that delivers 57-72 lp/mm resolution with automatic brightness control and cut-off circuitry that automatically interrupts power to the tube in the presence of bright light sources. The PVS-14 features 1.0x magnification, providing a 40 degree angle of view that aids situational awareness and allows the operator to effectively use a both eyes open technique in low-light conditions. The standard viewing angle combined with bright f/1.12 optics makes this monocular suited for aviation, close-quarter engagement, surveillance and recon. This NVD is head, helmet, weapon, camera, and tripod-mountable; when used with the wide range of compatible accessories, the PVS-14 can handle almost any low-light/no-light mission.
Intensifier Tube Gen III
Resolution 57 - 72 lp/mm
Magnification 1.0x
Angle/Field of View 40°
Lens System 26mm, f/1.2
Eye Relief 25 mm
Minimum Focus Distance 10" (26 cm)
Dioptric Correction -6 to 2
Infrared Illuminator Yes
Power Supply (1) AA battery
Runtime Up to 40 hours of continuous operation at room temperature
Weatherproofing Submersible to 66 ft (20 m)
Operating Temperature -60 to 120°F (-51 to 49°C)
Storage Temperature -60 to 185°F (-51 to 85°C)
Dimensions 4.5 x 2.4 x 2" (11 x 6 x 5 cm)
Weight 13.5 oz (380 g)
